Approval: CE, UKCA, UL Listed, FCC, IC, TÜV
Sensor principle: Transponder
Coding level to ISO 14119: Low
Classification to EN 60947-5-3: PDDB
Transponder coding: coded
Reset type: Automatic reset
Suitable for series connection: yes
Supply voltage (V): 24 V
Type of supply voltage U1: DC
Type of power supply for U1: SELV/PELV
Power consumption DC: 0.5
Number of OSSD outputs: 2
Number of sig. outputs: 1
Potential isolation of S/C O: No
S/C output short circuit proof: Yes
Utilisation cat. to EN 60947-1: DC-12
Ambient temperature standard: EN 60068-2-14
Ambient temperature: -10
Storage temperature standard: EN 60068-2-1/-2
Climatic suitability standard: EN 60068-2-78
Humidity rating: P_FEUCHTE_WERT_93 % r. F. bei 40 °C
Perm. operating height ASL: 2000 m
EMC to standard ...: EN 301489-1 V2.1.1, EN 55011: class A, EN 60947-5-3, EN 60947-5-2
Vibration to standard ...: EN 60947-5-2
Acc. shock to standard1: 30g
Overvoltage category: II
Pollution degree clear.&creep.: 2
Protection type, housing: IP20
UL enclosure type: type 1
Escape release available:No
Max. offset closing direction:+/-2 mm
Connection type:M12, 12pol. male
Max. cable length:45
Product material:Galvanised steel, Stainless steel, Plastic
Height dimension:157.5 mm
Width dimension:30.4 mm
Depth dimension:30.4 mm
Net weight:600 g
Gross weight: 610 g
