Electrical data | Supply
Operating voltage AC max. | 30 V |
Operating voltage DC max. | 30 V |
Total current max. | 10 A |
Installation
Connection cross section max. | 2,5 mm² |
AWG number min. | 28 |
AWG number max. | 14 |
Installation | Connection
Connection | Spring clamp plug-in terminals |
Device protection | Electrical
Degree of protection (EN IEC 60529) | IP20 |
Mechanical data | Mounting data
Height | 70 mm |
Width | 56 mm |
Depth | 32,5 mm |
Environmental characteristics | Climatic
Operating temperature min. | 0 °C |
Operating temperature max. | 55 °C |
Ambient temperature (storage, transport) | -40 °C … 85 °C |
