Approval: CCC, CE, UKCA, cULus Listed, KOSHA, EAC (Eurasian), TÜV
Supply voltage (V): 24 V
Type of supply voltage U1: DC
Power consumption DC: 2 W
Number of inputs: 1
Number of semicond. outputs:1
Utilisation cat. to EN 60947-1: DC-12
Utilisation cat. AC/DC1 stand.: EN 60947-4-1
Voltage AC1 safety cont.:240V
Max. current AC1 safety cont.:3 A
Voltage DC1 safety cont.:24 V
Max. current DC1 safety cont.:3 A
Utilisation cat. AC15/DC13sta.:EN 60947-5-1
Voltage AC15 safety cont.:230 V
Max. current AC15 safety cont.:1.5 A
Voltage DC13 safety cont.:24 V
Safety contacts: AC at UL:240 VAC G.U.
Safety contacts: pilot duty: R300, B300
Relay contact material:AgSnO2
Climatic suitability to ...:EN 60068-2-78
Ambient temperature: -10 °C
Humidity rating: 93 % r. h. at 40 °C
Condensation permitted: Not permitted
EMC to standard ...:EN 60947-5-1, EN 61000-6-2, EN 61000-6-4, EN 61326-3-1
Vibration to standard ...: EN 60068-2-6
Clearance & creepage dist. to: EN 60947-1
Overvoltage category: III / II
Pollution degree clear.&creep.: 2
Protection type, housing: IP40
Mounting position: any
Housing material lower section:PC
Housing material front plate:PC
Housing material upper part:PC
Connection terminal:Screw terminal
Terminal style:plug-in
Flex. cond. c/s AWG info: 24 - 12 AWG
Height dimension:98 mm
Width dimension:12.5 mm
Depth dimension:120 mm
Net weight:105 g
Gross weight:115 g
