Series: 8
Operating principle:Reflection principle
Special version: Autocollimation
Operating range: 0 ... 19 m (guaranteed operating range)
Operating range: 0 ... 21 m (typical operating range)
Light source: Laser, Red
Wavelength: 670 nm
Laser class: 2, IEC/EN 60825-1:2014
Mean life expectancy of laser:50,000 h
Transmitted-signal shape: Pulsed
Protective circuit: Polarity reversal protection, Short circuit protected
Supply voltage UB: 10 ... 30 V, DC
Residual ripple: 0 ... 15 %, From UB
Open-circuit current: 0 ... 35 mA
Open-circuit current: 0 ... 35 mA
Number of L/D changeover inputs: 1 Piece(s)
Type: L/D switching
Number of digital switching outputs: 2 Piece(s)
Type: Digital switching output
Switching element: Transistor, PNP
Switching principle: Light switching
Switching element: Transistor, PNP
Switching principle: Dark switching
Switching frequency: 2800 Hz
Response time: 0.18 ms
Readiness delay: 100 ms
Number of connections: 1 Piece(s)
Function: Signal IN, Signal OUT, Voltage supply
Type of connection: Connector, Turning, 90°
Thread size: M12
Type: Male
Material: Metal
No. of pins: 5 -pin
Encoding: A-coded
Dimension (W x H x L): 15 mm x 48 mm x 38 mm
Housing material: Metal
Plastic housing: Zinc
Lens cover material: Glass
Net weight: 70 g
Housing color: Red
Type of fastening: Through-hole mounting, Via optional mounting device, dovetail grooves, Mounting thread
Compatibility of materials: ECOLAB
Type of display: LED
Number of LEDs: 1 Piece(s)
Operational controls: Multiturn potentiometer
Ambient temperature, operation: -10 ...40 °C
Ambient temperature, storage: -40 ... 70 °C
Degree of Protection: IP 67, IP 69K
Protection class: III
Approvals: c UL US
Standards applied: IEC 60947-5-2
