Murr, MIRO 6.2 Pluggable Compl.module Output Relay, 3000-16013-3100020

Input voltage AC

24 V

Input voltage AC min.

19,2 V

Input voltage AC max.

28,8 V

Input voltage DC

24 V

Input voltage DC min.

19,2 V

Input voltage DC max.

28,8 V

Input current

12 mA

Switching voltage AC max.

250 V

Switching voltage DC max.

30 V

Switching current max.

6 A

Switching current DC

100 mA

Switching current DC min.

100 mA

Switching frequency max.

10 Hz

Power rating AC max.

1.500 VA

Power rating DC max.

180 W

Utilization category AC-12 (EN IEC 60947-5-1)

6 A @ 24 V 6 A @ 110 V 6 A @ 230 V

Utilization category AC-15 (EN IEC 60947-5-1)

3 A @ 24 V 3 A @ 110 V 1.5 A @ 230 V

Utilization category DC-13 (EN IEC 60947-5-1)

1 A @ 24 V 0.2 A @ 110 V 0.1 A @ 230 V

Status indication LED

green

Connection cross-section solid min.

0,34 mm²

Connection cross-section solid max.

2,5 mm²

Cross section connection with wire end ferrule min.

0,34 mm²

Cross section connection with wire end ferrule max.

1,5 mm²

Cross section connection with wire end ferrule AWG min.

22 AWG

Cross section connection with wire end ferrule AWG max.

14 AWG

AWG number solid min.

22

AWG number solid max.

14

Connection

springloaded terminal with push-in connection

Stripping length

10 mm

Condition lifetime

load-dependent

Degree of protection (EN IEC 60529)

IP20

Electrical lifetime NC

10.000 cycles

Electrical lifetime NO

30.000 cycles

Rated insulation voltage

250 V

Mechanical endurance

0 cycles

Response time max.

8 ms

Drop-out time max.

4 ms

Material contact

Ag Sn O2

Height

93 mm

Width

6,2 mm

Depth

75,6 mm

Mounting method

geschnappt

Suitable for mounting type

(EN 60715), mounting rail

Operating temperature min.

-25 °C

Operating temperature max.

60 °C
